Technical parameter
Camera
| Megapixel | 9MP |
| Image Sensor | 2*1/2.9’’ illumination CMOS Sensor |
| Min. Illumination | Color: 0.01Lux @ (F1.2AGC ON): 0 Lux with IR B/W: 0.001Lux @ (F1.2AGC ON): 0 Lux with IR |
| Shutter Speed | 1/50(1/60)s to 1/10,000s |
| Lens | 2.8mm(W) and 6mm(L)* |
| Day & Night | AI-ISP Black Light Full-Color Night Vision |
| DNR | Support 2D/3D Noise Reduction |
| WDR | Supports |
| Zoom | Digital Zoom 10X |
| Led | Led Lights and Alarm Led Indicator |
4G Connection
| Frequency Band | LTE-FDD：B1/B3/B5/B8 LTE-TDD：B34/B38/B39/B40/B41 |
| Rate | Upstream up to 2Mbps, downstream up to 6Mbps |
Compression
| Video Compression | H.265Ai |
| Audio Interface | Support Microphone Input & Support SPK Output Support Speaker Output Playback |
| Audio Compression | G.711A Code Standard, Support Dual Voice Talk-Back, Audio and Video Synchronization |
Interface
| Audio Input | Mic |
| Audio Output | In-build Speaker 1 Watt |
| Storage Interface | Support TF Card Up-To 256GB |
| Button | Reset Button |
| SIM Interface | 1 SIM insert |
| Motor Interface | 1 Horizontal Motor, 1 Vertical Motor |
Power Information
| Solar Panel | 9 Watt |
| Operating Power | 0.9A |
| Battery Type | Lithium-Ion Battery |
| Battery Backup | Up-to 10-15 Days Battery Back-up** and 24X7 Recording |
| Charging Port | C-Type DC Input |
General
| Operating Temperature | -10⁰C ~ 70⁰C |
| Operating Humidity | Humidity less than 90% (non-condensing) |
| Infrared Distance | Up To 60 mtr*** |
| Viewing Angle | 355⁰ |
| Ultra-Wide | 180° |
| Housing | ABS High Quality Plastic |
| Reliability | Comprehensive Lightning Protection in Line with National and International Standards: 3 hours High-Temperature Test Stability and Reliability |
| Smart Alarm | Human Detection, Motion Tracking, Support to Customizing other Intelligent Functions, Smart Police Siren |
| Functions | Support AI-HSP Black Light Full-Color Night Vision, Support 1 second Frame Recording (AOV state) + Full Frame Rate Recording (Wake-up State); Push alarm messages, Support MJPEG Capture |
| Supported Device | Android, IOS |
